3-62
Confidential
(3) Remove the Refill earth sheet.
Fig. 3-57
(4) Remove the Refill frame upper.
Fig. 3-58
Refill earth sheet
<Front>
Ink refill unit
Refill frame upper
<Front>
Ink refill unit
