3-109
Confidential
(3) Remove the four Taptite cup S M3x6 SR screws to remove the Power supply PCB ASSY.
Fig. 3-127
Taptite cup S M3x6 SR
Taptite cup S M3x6 SR
Taptite cup S
Main body
Power supply PCB ASSY
M3x6 SR
<Back side>
