3-141
Confidential
Fig. 3-177
Assembling Note:
When assembling the Paper feed jam actuator to the Outer chute ASSY, be sure to assem-
ble the LT actuator spring as shown in the figure below.
LT actuator spring
Paper feed jam actuator
Outer chute ASSY
