Brother HL-S7000DN - Page 388

4-45
Confidential
<New Type>
Fig. 4-20
100±50
150±50
150±50
Double carton
Double carton upper
Carton joint
Double carton spacer
Double carton bottom
Packed
Front side of machine
Carton joint
Double carton spacer bottom
PP Band
PP Band stopper
Packing tape
Front side of machine
(The PP band stopper
must come to the side face.)
spacer
machine
