 Sub tank ASSY
Fig. 5-15
 Drive frame ASSY
Fig. 5-16
Cap position sensor
Uncap position sensor
Ink full sensor
Pre-coat ink full sensor
Sub tank valve sensor
Sub tank leak sensor
Air Valbe home position sensor
Water full sensor
Drive switching home
Drive switching position sensor
position sensor
