Brother HL-S7000DN Service Manual

5-48
Confidential
*1
The types of purge operations are shown below.
1 Model name 29 Remaining rate of PF Kit 1/2/3/4
2 Serial number 30 Total of printed pages
3 Model code 31 Cumulative average coverage rate
4
Country code
32
Average coverage rate with the ink cartridge
in use
5
Main SW CheckSum
33
Number of sheets printed with the ink
cartridge in use
6
Engine SW CheckSum
34
Number of sheets printed with the previous
ink cartridge
7 Main firmware version 35 Drying stop page count
8 Rip firmware version 36 Total of printed pages by each paper tray
9
Boot firmware version
37
Number of sheets where two-sided are
printed
10
RIP Boot version
38
Total of printed pages by each eject stopper
tray
11
Engine Sub/Engine main/
Engine Boot ROM version
39
Total of printed pages by each type of paper
12
FPGA Libra/Gemini/Leo ROM size
40
Dot count of each head by printing, purge, or
flashing,waste ink box count
13 ROM CheckSum 41 Dot count of the ink cartridge in use
14
USB ID code
42
Total of purge operations performed in A
(auto) and M (manual) by each head
15
RAM size
43
Number of purge operations performed in A
(auto) and M (manual) by purge type
*1
16 RTC Check result 44 Uncap flashing count
17 RTC Backup result 45 Total flashing count
18 Before RTC Backup 46 Regular (tFL)/Powerful(Fd) flashing count
19
After RTC Backup
47
Number of supply operations from ink
cartridge to sub tank
20 USB product ID 48 Cumulative hours of current conduction
21 Main PCB inspection log 49 Number of times that the power is turned ON
22
Process inspection log
50
Temperature and humidity under which
maintenance information is printed
23 Process inspection log 51 Machine error history
24
Process inspection log
52
Number of times that each consumable part
has been replaced
25
Remaining rate of ink
53
Number of sheets jammed at each location of
the machine
26 Remaining rate of pre-coat ink 54 Operating state of engine sensor
27 Remaining rate of waste ink box 55 Engine error history
28
Remaining rate of PF Kit MP
56
LT1/2/3/Optional output tray main/Boot ROM
version
eIP: Engine initial purge PP2: High power purge
uIP: User initial purge NIP: Ink removal purge
RP: Periodical reset purge JP: After jam ink purge
NP: Normal purge JPH: After jam mist purge
RP2: Reset purge Stepup: Step up purge
PP: Power purge

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
