■ Error code 2101
Detected operational error from pick-up motor of tray 1.
Error code 2102
Detected operational error from pick-up motor of tray 2.
Error code 2103
Detected operational error from pick-up motor of tray 3.
Error code 2104
Detected operational error from pick-up motor of tray 4.
<User Check>
- Remove jammed paper from the relevant tray.
Print Unable 21
Turn the power off and then back on again.
Print Unable 21
Turn the power off and then back on again.
Print Unable 21
Turn the power off and then back on again.
Print Unable 21
Turn the power off and then back on again.
Step Cause Remedy
1 Pick up motor harness
connection failure
Reconnect the pick up motor harness.
2 Foreign object inside each paper
feed ASSY
Remove foreign object inside of each
paper feed ASSY.
3 Paper feed PCB failure Replace the paper feed PCB ASSY.
4 LT relay PCB failure Replace the LT relay PCB ASSY.
5 Power supply PCB failure Replace the power supply PCB ASSY.
6 Main PCB failure Replace the main PCB ASSY.
