Disassembly/Assembly > List of Parts > Single-sided Printer Unit > List of Solenoid
Disassembly/Assembly > List of Parts > Single-sided Printer Unit > List of Solenoid
●
List of Switch and Speaker
[1]
[2]
[3]
No. Name Reference Remarks
[1] Speaker
[2] Power Switch
[3] Door switch
F-4-13
●
List of Heater/Thermoswitch/Thermistor
[1]
[2]
[3]
No. Name Reference Remarks
[1] Thermoswitch
[2] Fixing Heater - -
[3] Thermistor - -
F-4-14
