Cisco ASR 1001 Hardware Installation Guide

Figure 172: Cisco ASR 1002-X Router +24 VDC Power Supply Lead Wire Fully Inserted, on page 361 shows the lead
wire fully inserted.
Figure 172: Cisco ASR 1002-X Router +24 VDC Power Supply Lead Wire Fully Inserted
——
Fully-inserted lead wire1
Step 7
After the lead wire is fully inserted, perform these steps:
a) Hold the lead wire in place while you remove the screwdriver.
b) After the screwdriver is completely removed, gently tug the lead wire to ensure that it is securely installed.
Figure 173: Removing a Screwdriver from the +24 VDC Power Supply Terminal Block, on page 361 shows a lead
wire that is fully inserted, and the screwdriver being removed while you gently tug the lead wire.
Figure 173: Removing a Screwdriver from the +24 VDC Power Supply Terminal Block
——
Gently tug the lead wire.1
Step 8
Repeat Steps 5 through Step 10 for each lead wire.
Figure 174: Cisco +24 VDC Power Supply Terminal Block with Lead Wires Installed, on page 361 shows all the lead
wires installed.
Figure 174: Cisco +24 VDC Power Supply Terminal Block with Lead Wires Installed
Ground lead wire3Positive lead wire1
——
Negative lead wire2
Ensure that the stripped end of each lead wire is twisted tightly together. This makes insertion easier. Also
ensure that the entire lead wire is inserted all the way into its receptacle. If exposed wire is visible at the stripped
end of a lead after inserting the lead into its receptacle, remove the lead from the receptacle, use the wire stripper
to cut the stripped end of the lead, and then reinsert.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
361
Cisco ASR 1002-X Router Overview and Installation
Connecting the +24 VDC Power Supply to the Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
