Cisco ASR 1002-X Hardware Installation Guide

•
Provide hardware abstraction layer between the packet processing-based forwarding engine and other
system components.
The Cisco ASR1000-ESP5, Cisco ASR1000-ESP10, Cisco ASR1000-ESP10-N, Cisco ASR1000-ESP20,
Cisco ASR1000-ESP40, Cisco ASR1000-ESP100, and Cisco ASR1000-ESP200 provide centralized
forwarding-engine options for the Cisco ASR 1000 Series Aggregation Services Routers. The Cisco ASR
1002-F Router includes a nonmodular, integrated embedded services processor with a forwarding bandwidth
(throughput) of 2.5 Gbps. The integrated embedded services processor of the Cisco ASR 1002-X Router can
provide a forwarding bandwidth of 5 Gbps, 10 Gbps, 20 Gbps, or 36 Gbps.
The Cisco ASR1000-ESP10-N is the nonencryption version of the Cisco ASR1000-ESP10. The Cisco
ASR1000-ESP10-N can only support noncrypto Cisco IOS software images. It does not support encryption
capabilities such as IPsec.
The Cisco ASR 1000 Series Routers support the following Cisco ASR 1000 Series Embedded Services
Processors:
The embedded services processor can be upgraded only on redundant embedded services processor systems
(Cisco ASR 1006 Router and Cisco ASR 1013 Router). The Cisco ASR 1002 router supports only one
Cisco ASR1000-ESP5 or ASR1000-ESP10. The Cisco ASR 1006 Router and Cisco ASR 1004 Router
do not support the Cisco ASR1000-ESP5. When performing upgrades, the Cisco ASR1000-ESP10, Cisco
ASR1000-ESP20, and any future ESPs can be upgraded.
Note
Do not have different embedded services processors operating in the same chassis. The only time this
condition occurs is when you are performing an upgrade.
Note
•
Cisco ASR 1000-ESP5, page 88
•
Cisco ASR 1000-ESP10, page 89
•
Cisco ASR 1000-ESP20, page 89
•
Cisco ASR 1000-ESP40, page 89
•
Cisco ASR 1000-ESP100, page 90
•
Cisco ASR 1000-ESP200, page 91
•
Features of the Cisco ASR 1000 Series Embedded Services Processors, page 94
Cisco ASR 1000-ESP5
The Cisco ASR1000-ESP5 forwarding performance will vary depending on features configured. Up to 4 Mpps
for the combination of the following commonly-used features: IPv4 forwarding, IP Multicast, ACL, QoS,
Reverse Path Forwarding (RPF), load balancing, and Sampled NetFlow.
Cisco ASR 1000 Series Router Hardware Installation Guide
88
Cisco ASR 1000 Series Routers Embedded Services Processors
Cisco ASR 1000-ESP5

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
