The Cisco ASR 1000-ESP5 can only be used in the Cisco ASR 1002 Router.Note
Power Supplies in the Cisco ASR 1002 Router
The Cisco ASR 1002 Router power supply module supports the following Cisco power supplies:
• AC power supply operates between 85VAC to 264VAC and DC operates between –40.5 to –72VDC
• –48 VDC power supply operates between
•
+24 VDC power supply operates
The power supplies are installed into the rear of the chassis and are hot pluggable. The Cisco ASR 1002 Router
supports up to 588 W input power from an infrastructure standpoint (cooling capacity, midplane and power
distribution) but initial power supply development limit is up to 470 W output (AC and DC Input).
AC Power Supply for Cisco ASR 1002 Router
The AC power supply input inlet is an IEC connector with AC switch and the current rating on the connector
and switch is 10 Amps. The AC power supply is secured into the chassis with two captive screws mounted
on the faceplate.
The following table describes the AC power supply LEDs on the Cisco ASR 1002 Router.
Table 53: Cisco ASR 1002 Router AC Power Supply LEDs
DescriptionColorLEDLED Label
The AC input voltage is greater
than 85V.
GreenPower supply activityINPUT OK
If the LED is not illuminated,
then either the input voltage is
less than 70V, or the power
supply is turned off.
If the AC input voltage is
between 70V and 85V, the
INPUT OK LED can be on, off,
or flashing.
None
All fans are operational.GreenPower supply fan activity
A bi-color LED indicates fan
status.
FAN OK
A fan failure is detected.Red
Cisco ASR 1000 Series Router Hardware Installation Guide
226
Cisco ASR 1002 Router Overview and Installation
Power Supplies in the Cisco ASR 1002 Router
