Cisco ASR 1002-X Hardware Installation Guide

AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
For example, the
Cisco ASR 1002
Router –48
VDC power
supply, with 16
Amp input
rating must use
an AWG #12
gauge wire for a
20 A circuit
breaker and an
AWG #10 gauge
wire for a 30 A
circuit breaker.
All Cisco ASR 1000 Series Router AC power supplies must be connected to a branch circuit that does
not exceed 20 A.
Note
Detailed instructions for removing and replacing the Cisco ASR 1000 Series AC and DC power supplies
are in Chapter 14, “Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers.”
Note
Power Cords Supported by the Cisco ASR 1004 Router
Table 51: Power Cords Supported by the Cisco ASR 1004 Router , on page 209 lists the power cords that are
supported by the Cisco ASR 1004 Router.
Table 51: Power Cords Supported by the Cisco ASR 1004 Router
DescriptionPower Cord Item Number
Power Cord, 110 V, Right AngleCAB-AC-RA
10 A AC Power Cord, Left Angle (Australia) (bundle
option)
CAB-AC10A-90L-AU
10 A AC Power Cord, Left Angle (Europe) (bundle
option)
CAB-AC10A-90L-EU
10 A AC Power Cord, Left Angle (Italy) (bundle
option)
CAB-AC10A-90L-IT
Cisco ASR 1000 Series Router Hardware Installation Guide
209
Cisco ASR 1004 Router Overview and Installation
Power Cords Supported by the Cisco ASR 1004 Router

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
