Cisco ASR 1002-X Hardware Installation Guide

DescriptionDirectionSignalPin
——
N/C7,8
Cisco ASR 1002-X Router BITS Port Signals and Pinouts
The following table lists the pinout of the front panel Building Integrated Timing Supply (BITS) RJ45 port
on the Cisco ASR 1002-X Router.
Table 115: BITS RJ-45 Interface Pinouts for Cisco ASR 1002-X Router
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive TIP (T1/E1)InputRX TIP2
Not used
—
N/C3, 4
Transmit RingOutputTX Ring5
Transmit TIP (T1/E1)OutputTX TIP6
——
N/C7,8
Cisco ASR 1002-X Router BNC GPS Ports
The following table describes the BNC GPS ports on the Cisco ASR 1002-X.
Table 116: GPS Port Pinout
1PPS (input and output)10 Mhz (input and output)Signal Attribute
Input—Pulse shape
Output—Pulse shape
Input—Sine wave
Output—Square wave
Waveform
Input— > 2.4 volts TTL
compatible
Output— > 2.4 volts TTL
compatible
Input— > 1.7 volt p-p(+8 to +10
dBm)
Output— > 2.4 volts TTL
compatible
Amplitude
50 ohms50 ohmsImpedance
26 microseconds50% duty cyclePulse Width
Cisco ASR 1000 Series Router Hardware Installation Guide
629
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002-X Router BITS Port Signals and Pinouts

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
