Cisco ASR 1002-X Hardware Installation Guide

SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1004 Router Specifications
This section lists the specifications for the Cisco ASR 1004 Router.
The following table lists the Cisco ASR 1004 Router physical specifications.
Table 103: Cisco ASR 1004 Router Specifications
SpecificationDescription
Connects the Cisco ASR 1000 Series RP1, ASR 1000 Series ESP,
Cisco ASR 1000 Series SPA Interface (SIP), SPAs, and power
supplies together in the system
Midplane
Height = 7 in. (17.8 cm) (4RU rack-mount per EIA RS-310)
Width = 17.25 in. (43.815 cm) (19 inch rack-mount or optional
23 Telco rack- mount)
Depth = 22.50 in. (57.15 cm) (including card handles,
cable-management brackets and power supply handles)
Dimensions (H x W x D)
•
Fully loaded chassis: 50 pounds (22.6796 kg)
•
Only chassis: 18 pounds (8.16 kg)
Weight
•
41° to 104° F
•
5° to 40° C
Nominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum DC: 1020W
•
Maximum AC: 960W
•
Maximum (Out): 765W
Power consumption
Cisco ASR 1000 Series Router Hardware Installation Guide
621
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router Specifications

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
