Cisco ASR 1002-X Hardware Installation Guide

Step 3
After you establish normal router operation, you can disconnect the console terminal.
What to Do Next
A connection will not be established when setting up an out-of-band connection or modem connection in
the auxiliary port and the console port.
Note
Connecting a Cable to the Management Ethernet Port
This section describes how to attach a cable to the Cisco Management Ethernet port on the Cisco ASR 1002-F
Router.
Step 1
Insert an Ethernet RJ-45 cable into the MGMT ETHERNET port (see ).
Figure 136: Cisco ASR 1002-F Router Integrated RP Management Ethernet Port Connector
Management Ethernet port1
Step 2
Insert the other end of the RJ-45 cable into your management device or network.
Step 3
Configure the port connection to a fixed speed through the command-line interface (CLI).
Connecting Power to the Cisco ASR 1002-F Router
The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed in empty slots. Statement 1077
Warning
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Cisco ASR 1000 Series Router Hardware Installation Guide
306
Cisco ASR 1002-F Router Overview and Installation
Connecting a Cable to the Management Ethernet Port

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
