Table 75: +24 VDC Output Voltage Alarm Threshold Ranges
MaximumMinimumOutput
12.8-13.8 V10.0-11.2 V12 V
None
2.6 – 3.0 V
3.3 V
• Temperature—If a fan fails, the power supply meets the functional requirements specified in above
table. The calculated MTBF does not apply above 55°C with less than two fans. However, all the
component stress remains within the manufacturer’s specified rating.
• Thermal shutdown—The +24 VDC power supply shuts down to protect its components due to excessive
internal temperature. The +24 VDC power supply then automatically restarts after the internal temperature
returns to a safe operating level.
Power Cords Supported by the Cisco ASR 1002-X Router
The following table lists the power cords that are supported by the Cisco ASR 1002-X Router.
Table 76: Power Cords Supported by the Cisco ASR 1002-X Router
DescriptionPower Cord Item Number
Power Cord, 110 V, Right AngleCAB-AC-RA
Plug, Power Cord, Australia, 10 A, Right AngleCAB-ACA-RA
Power Cord, Brazil, Right Angle, 10 ACAB-ACB10A-RA
Power Cord, Brazil, Right Angle, 16 ACAB-ACB16A-RA
Power Cord, China, Right AngleCAB-ACC-RA
Power Cord, Europe, Right AngleCAB-ACE-RA
Power Cord, Italy, Right AngleCAB-ACI-RA
Power Cord, Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord, UK, Right AngleCAB-ACU-RA
Power Cord, India, Right AngleCAB-IND-RA
Power Cord, Japan, Right AngleCAB-JPN-RA
Cisco ASR 1000 Series Router Hardware Installation Guide
330
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router
