Page #570 background imageLoading...
Page #570 background image
Removing the Cisco ASR 1000 SPA Interface Processor
To remove a SPA Interface Processor (SIP) in the Cisco ASR 1006 Router and Cisco ASR 1004 Router,
follow these steps.
SUMMARY STEPS
1.
Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the captive screws
on the Cisco ASR 1000 Series SPA Interface Processor.
2.
Using the handles on both sides of the module, with two hands gently slide the Cisco ASR 1000 Series
SPA Interface Processor out of the chassis slot.
3.
Place the Cisco ASR1000-SIP10 on an antistatic surface with its printed circuit board components facing
upward or in a static shielding bag.
DETAILED STEPS
Step 1
Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the captive screws on the Cisco
ASR 1000 Series SPA Interface Processor.
Step 2
Using the handles on both sides of the module, with two hands gently slide the Cisco ASR 1000 Series SPA Interface
Processor out of the chassis slot.
Handle the Cisco ASR1000-SIP10 by the card edges only; never touch the printed circuit board components or
connector pins.
Note
Step 3
Place the Cisco ASR1000-SIP10 on an antistatic surface with its printed circuit board components facing upward or in
a static shielding bag.
For detailed information about installing and removing SIPs and SPAs, see Cisco ASR 1000 Series Aggregation Services
Routers SIP and SPA Hardware Installation Guide .
What to Do Next
You have completed the removal procedure for the Cisco ASR1000-SIP10.
Replacing the Cisco ASR 1000 SPA Interface Processor
To replace a SPA Interface Processor (SIP), follow these steps.
SUMMARY STEPS
1.
Before inserting a SIP, make sure that the chassis is grounded.
2.
To insert the SIP, carefully align the edges of the SIP between the upper and lower edges of the router
slot.
3.
Carefully slide the SIP into the router slot until the SIP makes contact with the backplane.
4.
Tighten the locking thumbscrews on both sides of the SIP.
5.
Connect all cables to each SPA.
Cisco ASR 1000 Series Router Hardware Installation Guide
536
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR 1000 SPA Interface Processor
