Cisco ASR 1002-X Hardware Installation Guide

Power Supply Requirements for All Cisco ASR 1000 Series Routers
This section contains power supply specifications for all Cisco ASR 1000 Series Routers. The following topics
are covered:
•
DC power supply input ratings and circuit breaker specifications
◦
Maximum and minimum Amps for the branch circuit breakers
◦
Maximum and minimum size of the AWG wire required for each circuit breaker.
•
AC and DC power supply types
•
AC and DC power supply ratings
DC Power System Input Requirements for Cisco ASR 1000 Series Routers
The DC power supply for the Cisco ASR 1006, Cisco ASR 1004, Cisco ASR 100, Cisco ASR 1013, and Cisco
ASR 1001 routers operate at individual specifications.
The following table shows the common input ranges and circuit breaker requirements.
Table 14: Cisco ASR 1000 Series Router DC Power Supply System Input Requirements
AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
MaximumMinimumMaximumMinimum
Always AWG
#6 wire
Always 5040Cisco ASR 1006
810403024Cisco ASR 1004
Cisco ASR
1002:
• –48 VDC
•
+24 VDC
1012302016
88404032
Always AWG
#6 wire
Always 5040Cisco ASR 1013
1010302014Cisco ASR 1001
Cisco ASR 1000 Series Router Hardware Installation Guide
49
Cisco ASR 1000 Series Routers Component Overview
Power Supply Requirements for All Cisco ASR 1000 Series Routers

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
