Cisco ASR 1002-X Hardware Installation Guide

Table 136: Console Port Pinout for Cisco ASR1000-ESP100
DescriptionDirectionSignalPin
Request to send, tied to
CTS
INRTS1
UnusedOUTDTR2
Transmit dataOUTTXD3
GroundGroundGND4
GroundGroundGND5
Receive dataINRXD6
UnusedINDSR7
Clear to send, tied to RTSOUTCTS8
Cisco ASR1000-ESP200 Console Port Pinout Specifications
Cisco ASR1000-ESP200 provides a debug console on an 8-pin header. The following table lists the console
port pinouts for Cisco ASR1000-ESP200.
Table 137: Console Port Pinout for Cisco ASR1000-ESP200
DescriptionDirectionSignalPin
Request to send, tied to
CTS
INRTS1
UnusedOUTDTR2
Transmit dataOUTTXD3
GroundGroundGND4
GroundGroundGND5
Receive dataINRXD6
UnusedINDSR7
Clear to send, tied to RTSOUTCTS8
Cisco ASR 1000 Series Router Hardware Installation Guide
643
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Cisco ASR1000-ESP200 Console Port Pinout Specifications

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
