Cisco ASR1000-ESP40 Console Port Pinout Specifications
Cisco ASR1000-ESP40 provides a debug console on a 10-pin header. The following table lists the console
port pinouts for Cisco ASR1000-ESP40.
Table 135: Console Port Pinout for Cisco ASR1000-ESP40
DescriptionDirectionSignalPin
Not Connected
——
1
UnusedInDSR2
Receive DataInRXD3
Request to send, tied to
CTS
InRTS4
Transmit dataOutTXD5
Clear to Send, tied to RTSOutCTS6
Data Terminal Ready
(Always On)
OutDTR7
Not Connected
——
8
GroundGroundGND9
Cisco ASR1000-ESP100 Console Port Pinout Specifications
Cisco ASR1000-ESP100 provides a debug console on an 8-pin header. The following table lists the console
port pinouts for Cisco ASR1000-ESP100.
Cisco ASR 1000 Series Router Hardware Installation Guide
642
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Cisco ASR1000-ESP40 Console Port Pinout Specifications

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
