DescriptionDirectionSignalPin
——
NC7,8
Cisco ASR 1006 Router BITS Port Signals and Pinouts
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) RJ45 port on the Cisco
ASR 1006 Router.
Table 98: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive (T1/E1)InputRX2
——
N/C3, 4
—
UnusedTX Ring5
—
UnusedTX6
——
N/C7,8
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) and the DOCSIS Timing
Interface (DTI) RJ45 port on the Cisco ASR1000-RP2 front panel.
Table 99: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
DescriptionDirectionSignalPin
Receive
Ring/Bidirectional DTI
Input/Bi (DTI)RX Ring1
Receive TIP (T1/E1)
Bidirectional DTI
Input/Bi (DTI)RX TIP2
——
N/C3, 4
Transmit
Ring/Bidirectional DTI
OutputTX Ring5
Transmit TIP (T1/E1)
Bidirectional DTI
OutputTX6
——
N/C7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
618
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1006 Router BITS Port Signals and Pinouts

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
