Cisco ASR 1002-X Hardware Installation Guide

DescriptionDirectionSignalPin
Receive DataInput
RX Data–
6
——
NC7,8
BITS Interface Port Signals and Pinouts
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) RJ45 port.
Table 128: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive (T1/E1)InputRX TIP2
——
N/C3, 4
—
UnusedTX Ring5
—
UnusedTX TIP6
——
N/C7,8
Console Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the front panel console port.
Table 129: Console Port Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Request to Send (tied to
pin 8, CTS)
OutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
GND4
——
GND5
Cisco ASR 1000 Series Router Hardware Installation Guide
638
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
BITS Interface Port Signals and Pinouts

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
