Cisco ASR 1002-X Hardware Installation Guide

Cisco ASR 1013 Router Console Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the front panel console port.
Table 121: Console Port Pinouts for Cisco ASR 1013 Router
DescriptionDirectionSignalPin
Request to Send (tied to
CTS)
OutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
GND4
——
GND5
Receive DataInputRXD6
unusedInputDSR7
Clear to Send (tied to
RTS)
InputCTS8
Cisco ASR 1013 Router Auxiliary Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the auxiliary port signals.
Table 122: Auxiliary Port Pinouts for Cisco ASR 1013 Router
DescriptionDirectionSignalPin
Request to SendOutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
RI4
——
GND5
Receive DataInputRXD6
Cisco ASR 1000 Series Router Hardware Installation Guide
633
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Console Port Signals and Pinouts

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
