Cisco ASR 1002-X Hardware Installation Guide

SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
—
1745Minor Audible
Alarm
MINAA
—
18619Critical Visual
Alarm
CRTVA
—
2078Major Visual
Alarm
MAJVA
—
21922Minor Visual
Alarm
MINVA
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1001 Router Specifications
This section lists the specifications for the Cisco ASR 1001 Router. The following table lists the Cisco ASR
1001 Router physical specifications.
The Cisco ASR 1001 Router has the route processor, embedded services processor, and SIP integrated in
the chassis.
Note
Table 125: Cisco ASR 1001 Router Specifications
SpecificationDescription
Height: 1.71 in. (43.43 mm)
Width: 17.3 in. (439.42 mm)
Depth: 22.50 in. (571.5 mm) including card handles,
cable-management brackets, and power supply
handles)
Dimensions (H x W x D)
•
23.30 lb (10.6 kg) (with dual AC power and
integrated daughter card)
•
22.70 lb (10.3 kg) (with dual DC power and
integrated daughter card)
•
25 lb fully loaded
Weight
Cisco ASR 1000 Series Router Hardware Installation Guide
635
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1001 Router Specifications

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
