Cisco ASR 1002-X Hardware Installation Guide

DescriptionPower Cord Item Number
10 A AC Power Cord, Left Angle (United Kingdom)
(bundle option)
CAB-AC10A-90L-UK
15 A AC Power Cord, Left Angle (United States)
(bundle option)
CAB-AC15A-90L-US
Plug, Power Cord, Australian, 10 A, Right AngleCAB-ACA-RA
Power Cord, Brazil, Right Angle, 10 ACAB-ACB10A-RA
Power Cord, Brazil, Right Angle, 16 ACAB-ACB16A-RA
Power Cord China, Right AngleCAB-ACC-RA
Power Cord Europe, Right AngleCAB-ACE-RA
Power Cord, Italian, Right AngleCAB-ACI-RA
Power Cord Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord UK, Right AngleCAB-ACU-RA
Power Cord-Japan, Right AngleCAB-JPN-RA
Connecting AC Input Power to Cisco ASR 1004 Router
Follow these steps to connect an AC input power supply to the Cisco 1004 chassis:
SUMMARY STEPS
1.
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
2.
Tighten the captive screws.
3.
Insert the AC power cable into the power inlet.
4.
Plug the power supply cable into the power source.
5.
Turn the power supply switch to the On position.
Cisco ASR 1000 Series Router Hardware Installation Guide
210
Cisco ASR 1004 Router Overview and Installation
Connecting AC Input Power to Cisco ASR 1004 Router

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
