SpecificationDescription
Height: 3.5 in. (8.9 cm)
Width: 17.25 in. (19-inch rack-mount or optional 23 Telco adaptor
brackets)
Depth: 22.50 in. (including card handles, cable-management
brackets, and power supply handles) for mounting in a
600mm-enclosed cabinet
Dimensions (H x W x D)
•
40 lbs (18.143 kg) for a fully loaded Cisco ASR 1002 Router
or Cisco ASR 1002-F Router
•
43.35 lbs (19.662 kg) for a fully loaded Cisco ASR 1002-X
Router
Weight
•
41° to 104° F
•
5° to 40° C
Nominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum DC: 590W
•
Maximum AC: 560W
•
Maximum (Out): 470W
Power consumption
Cisco ASR 1002 Router Mgmt Ethernet RJ-45 Port Pinouts
Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
Note
The Cisco ASR 1002 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially.
The following table lists the RJ-45 port pinout for the front panel Management Ethernet port.
Cisco ASR 1000 Series Router Hardware Installation Guide
626
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router Mgmt Ethernet RJ-45 Port Pinouts
