Cisco ASR 1004 Router Memory and Storage Options
The following table lists the hardware memory and storage options supported on the Cisco ASR 1004 Router.
Table 104: Memory and Storage Options for Cisco ASR 1004 Router
Maximum System SupportDefaultMemory Type
4 GBDRAM2 GB DRAMRP1
For mass storage: hard disk drive 40 GB
or solid-state drive 32Gb support
1 GB (Partitioned: 2x32MB for NVRAM
and the remaining for mass storage
eUSB
Cisco ASR 1004 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1004 Router has RJ-45 port for the 10/100/1000 Ethernet connection. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially. See xref Figure A-1
to see an RJ-45 port and connector.
Cisco ASR 1004 Router MGMT Ethernet Port Signals and Pinouts
The following table lists the RJ-45 port pinouts for the front panel Management Ethernet port.
Table 105: RJ-45 Management Ethernet Port Pinouts for the Cisco ASR 1004 Router
DescriptionDirectionSignalPin
Transmit DataOutputTX Data+1
Transmit DataOutput
TX Data–
2
Receive DataInputRX Data+3
——
NC4, 5
Receive DataInput
RX Data–
6
——
NC7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
622
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router Memory and Storage Options
