Installation of the equipment must comply with local and national electrical codes. Statement 1074Warning
When installing or replacing the unit, the ground connection must always be made first and disconnected
last. Statement 1046
Warning
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority
or an electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning
This unit has two power supply connections. All connections must be removed to de-energize the unit.
Statement 1028
Warning
This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than: AC power supplies 20 A and DC power supplies 30 A. Statement
1005
Warning
Connecting AC Input Power to Cisco ASR 1002-X Router
This section provides the procedures for connecting AC-input, –48 VDC input power, and the +24 VDC input
power to your Cisco ASR 1002-X Router.
For detailed instructions for removing and replacing the Cisco ASR 1002-X Router AC and DC power supplies,
see Chapter 14, “Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers.”
To connect AC power to the Cisco ASR 1002-X Router, follow these steps:
SUMMARY STEPS
1.
At the rear of the router, ensure that the power switch is in the Off (O) position.
2.
Insert the AC power cable into the power supply AC inlet.
3.
To ensure that the AC power cord does not interfere with other cables or wires, dress the AC power cable
in one of the following ways.
4.
Plug the AC power supply cable into the AC power source.
DETAILED STEPS
Step 1
At the rear of the router, ensure that the power switch is in the Off (O) position.
Turn the power switch to the On (|) position after both sides of the power cord are connected.Note
Cisco ASR 1000 Series Router Hardware Installation Guide
352
Cisco ASR 1002-X Router Overview and Installation
Connecting AC Input Power to Cisco ASR 1002-X Router
