Cisco ASR 1002-X Hardware Installation Guide

•
Bulk file storage is on a large eUSB device (to 8 GB supported) with no SATA hard-drive supported.
•
Redundant Cisco Route Processor 1 is not supported.
•
Network clock changes. No second BITS clock input supported.
•
A built-in 4x1GE SPA is included. This shared port adapter provides four SFP-based GE connections.
For information about the SFP transceiver modules that are compatible with Cisco ASR 1002 Built-in Gigabit
Ethernet Ports (4x1GE), refer to the “Modular Optics Compatibility” section in Cisco ASR 1000 Series
Aggregation Services Routers SIP and SPA Hardware Installation Guide .
Cisco Embedded ASR1000-SIP10 and SPAs for Cisco ASR 1002 Router Description
The Cisco embedded ASR1000-SIP10 in the Cisco ASR 1002 Router is built into the Cisco ASR 1002 Router.
The Cisco embedded ASR1000-SIP10 provides the physical and electrical termination for up to three half-height
SPAs or one full-height and one half-height SPA. Double-wide SPAs are not supported. The fourth SPA slot
is connected to the built-in 4xGE SPA that resides on the Cisco embedded ASR1000-RP1.
The Cisco embedded ASR1000-SIP10 interface, like the Cisco ASR 1006 Router and Cisco ASR 1004 Router,
supports all Cisco embedded ASR1000-SIP10 functions and services. However, the Cisco embedded
ASR1000-SIP10 differs in the following areas:
•
Functions as the base board for Cisco embedded ASR1000-RP1
•
Only supports three removable half-height SPAs on Bay 1, 2, and 3. The fourth SPA is a built-in 4xGE
SPA on Bay 0, which is located on the Cisco embedded ASR1000-RP1.
•
Is not a field-replaceable unit (FRU) and does not support online insertion and removal (OIR).
The shared port adapters (SPAs) on the Cisco embedded ASR1000-SIP10 in the Cisco ASR 1002 Router
do support online insertion and removal.
Note
The Cisco ASR 1002 Router embedded ASR1000-RP1 also provides the circuitry for the built-in 4xGE SPA.
Cisco ASR1000-ESP5 and ASR1000-ESP10 Description
The Cisco ASR 1002 Router supports the Cisco ASR1000-ESP5 or Cisco ASR1000-ESP10 embedded services
processors. The Cisco ASR 1002 Router does not support the Cisco ASR1000-ESP20.
Cisco ASR 1000 Series Router Hardware Installation Guide
224
Cisco ASR 1002 Router Overview and Installation
Cisco ASR 1002 Router Components

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
