Cisco ASR 1002-X Hardware Installation Guide

Cisco ASR1000-RP2Cisco ASR1000-RP1
•
Up to 4 DIMMs with up to two DIMMs per
channel
•
DDR-533
•
Allowable memory options of 4 GB, 8 GB, or
16 GB
—
•
DDR-667
—
You might need to upgrade the DIMM for the following reasons:
•
You have upgraded to a new Cisco IOS feature set or release that requires more memory.
•
You are using very large routing tables or many protocols.
This section contains the following topics:
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006
Router and the Cisco ASR 1013 Router
The Cisco ASR 1006 Router and the Cisco ASR 1013 Router have redundant RPs. The following is an
overview of the steps to remove and replace the DIMM memory modules on these routers:
Cisco ASR 1000 Series Router Hardware Installation Guide
495
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006 Router and the Cisco ASR 1013 Router

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
