Cisco ASR 1002-X Hardware Installation Guide

Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Danger
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
This section provides the procedures for connecting AC-input and DC input power to your Cisco ASR 1002-F
Router.
The DC power supply for the Cisco ASR 1006, Cisco ASR 1004, Cisco ASR 1002, and Cisco ASR 1002-F
routers operate at individual specifications. The following table shows the common input ranges and circuit
breaker requirements.
Table 68: Cisco ASR 1000 Series Router DC Power Supply System Input Requirements
AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
MaximumMinimumMaximumMinimum
Always AWG
#6 wire
Always 5040Cisco ASR 1006
810403024Cisco ASR 1004
1012302016Cisco ASR 1002
and Cisco ASR
1002-F 1
1 The Cisco
ASR 1002-F
Router DC
power supply,
with 16 A input
rating must use
an AWG #12
gauge wire for a
20 A circuit
breaker and an
AWG #10 gauge
wire for a 30 A
circuit breaker.
Cisco ASR 1000 Series Router Hardware Installation Guide
307
Cisco ASR 1002-F Router Overview and Installation
Connecting Power to the Cisco ASR 1002-F Router

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
