Redundant Cisco route processor is not supported.
•
Network clock changes. No second BITS clock input supported.
•
A built-in 4xGE SPA is included. This shared port adapter provides four SFP-based GE connections.
The Cisco route processor common LEDs and indicators are shown in the “Common LEDs for Cisco ASR
1001 Route Processor” figure in the Cisco ASR 1001 Router Architecture section. The following table describes
the Cisco ASR 1000 Series Route Processor LEDs.
Table 81: Cisco ASR 1001 Series Route Processor LEDs
Behavior Description
Color—State
LEDLED Label
All power requirements are
within specification
Solid greenPowerPWR
Off. The router is in standby
mode.
Off
Cisco IOSD and other required
processes have loaded
successfully and are operating.
Solid greenSystem statusSTAT
ROMMON is running
(including a permanent failure
of RP software) or the Process
Manager has declared a critical
RP process (including IOSD)
dead. A user can log in to
recover.
Yellow
Occurs during system failure or
power-up.
Red
Functions as a critical alarm
indicator. The LED is lso a solid
red during the boot process.
Solid RedCriticalCRIT
Major alarm indicator.Solid RedMajorMAJ
Minor alarm indicator.AmberMinorMIN
Activity indicator.GreenInternal eUSB bootflash LEDBOOT
Link with no activity.Solid green10/100/1000 Interface LEDLINK
MGMT Ethernet port activity.Flashing Green
No link.Off
Cisco ASR 1000 Series Router Hardware Installation Guide
