Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Danger
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Danger
Use the information provided in this section to wire the DC input power source:
SUMMARY STEPS
1.
At the front of the router, ensure that the power switch is in the Standby position.
2.
Move the circuit-breaker switch handle to the Off position, and apply tape to hold it in the Off position.
3.
Gather the DC power supply terminal block plug.
4.
Insert the lead wires before inserting the plug into the terminal block header on the DC power supply.
5.
Use a 10 gauge wire-stripping tool to strip each of the three wires coming from the DC input power source.
If you are using the connector plug with the raised screw holes, strip the wires to 0.39 inch (10 mm) +
0.02 inch (0.5 mm). If you are using the connector plug with the screw holes that are not raised, strip the
wires to 0.27 inch (7 mm) + 0.02 inch (0.5 mm). Do not strip more than the recommended length of wire
because doing so could leave the wire exposed from the terminal block plug. The following figure shows
a stripped DC input power source wire.
6.
Identify the positive, negative, and ground feed positions for the terminal block connection. The
recommended wiring sequence is:
7.
Insert the exposed wire of one of the ground wire into the terminal block plug. Ensure that you cannot see
any wire lead. Only wires with insulation should extend from the terminal block.
8.
Use a ratcheting torque screwdriver to torque the terminal block plug captive screw (above the installed
wire lead) to from 0.5 Nm (4.425 lbf in. to 0.6 Nm (5.310 lbf in.), as shown in the following figure.
9.
Repeat Step 6 through Step 8 for the remaining two DC input power source wires, the positive lead wire
and the negative lead wire.
10.
Use a tie wrap to secure the wires to the rack, so that the wires are not pulled from the terminal block plug
by casual contact. Make sure the tie wrap allows for some slack in the ground wire. The following figure
shows the DC terminal block plug inserted and the tie wrap secured.
11.
Ensure that the terminal block plug is fully seated in the terminal block header on the DC power supply
panel. You will hear a snap or click when installed properly.
12.
Remove the tape (if any) from the circuit breaker switch handle, and move the circuit breaker switch
handle to the On position.
13.
At the rear of the router, place the power supply Standby switch in the On position to turn on the router.
