The following figure shows the DC power supply terminal block for the ASR1006-PWR-DC power supply of the Cisco
ASR 1006 Router.
Figure 267: Cisco ASR 1006 Router DC Power Supply (ASR1006-PWR-DC) Terminal Block and Plastic Cover
Plastic cover slotted area3Negative terminal1
Terminal block plastic cover4Positive terminal2
Cisco ASR 1000 Series Router Hardware Installation Guide
547
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing a DC Power Supply in Cisco ASR 1006 Router
