Cisco ASR 1002-X Hardware Installation Guide

SpecificationDescription
Height: 22.8 in. (579.1 cm)
Width: 17.2 in. (437.4 cm)
Depth: 22 in (558.8 cm) with cable-management bracket and
power supply handles included
Dimensions (H x W x D)
•
184.0 lb (83.46 kg) (with redundant AC power supply, SPA
and route processor and SIP blank covers, two embedded
services processors, two route processors, six SIPs, and no
SPAs)
•
190.60 pounds (loaded with DC power supplies) (86.45 kg)
•
Total with estimated superslot weights with:
◦ AC power supplies—202 pounds (91.62 kg)
◦ DC power supplies —208.60 (94.61 kg)
Using the Cisco ASR1000-ESP100 instead of the Cisco
ASR1000-ESP40 adds 2.1 lbs to the total weight of the
router.
Note
Weight
5° to 40° CNominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum input (DC): 4,200W
• Maximum input (AC – High Line): 4,000 W
• Maximum output (DC and AC – High Line): 3,390 W
Power consumption (2x Zones)
•
Maximum input (DC): 2100W
• Maximum input (AC – High Line): 2,000WMaximum input
(AC – Low Line): 1,760W
• Maximum output (DC and AC – High Line): 1,695W
• Maximum output (AC – Low Line): 1,415W
Per Power Supply Power Consumption
Cisco ASR 1000 Series Router Hardware Installation Guide
631
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Specifications

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
