The following figure shows the AC power supply LEDs and DB-25 alarm connector.
Figure 11: Cisco ASR 1006 Router AC Power Supply LEDs and DB-25 Alarm Connector
DB-25 alarm connector3AC power supply LEDs1
AC power supply fan4AC power supply fan2
The following table describes the AC power supply LEDs on the Cisco ASR 1006 Router.
Cisco ASR 1000 Series Router Hardware Installation Guide
54
Cisco ASR 1000 Series Routers Component Overview
AC Power Supply LEDs and Connector for Cisco ASR 1006
