After you complete the Cisco Business Edition 3000 First Time Setup Wizard, you are ready to set up the
Cisco gateway for PSTN connections.
For more details, see Cisco 3900 Series, 2900 Series, and 1900 Series Software Configuration Guide
located at http://www.cisco.com/en/US/partner/docs/routers/access/1900/software/configuration/guide/
Software_Configuration.html.
Note
To configure the gateway, perform the following procedure:
Procedure
Step 1
When you power on your Cisco gateway for the first time, the following information appears on your screen:
“Cisco Configuration Professional (Cisco CP) is installed on this device.
This feature requires the one-time use of the username cisco with the
password cisco. These default credentials have a privilege level of 15.
YOU MUST USE CISCO CP or the CISCO IOS CLI TO CHANGE THESE PUBLICLY-KNOWN
CREDENTIALS
Here are the Cisco IOS commands.
username <myuser> privilege 15 secret 0 <mypassword> no username cisco
Replace <myuser> and <mypassword> with the username and password you want
to use.
IF YOU DO NOT CHANGE THE PUBLICLY-KNOWN CREDENTIALS, YOU WILL NOT BE ABLE
TO LOG INTO THE DEVICE AGAIN AFTER YOU HAVE LOGGED OFF.”
At the User Access Verification screen, log in with default username cisco and password cisco:
Username: cisco
Password: cisco
Step 2
Enter the following commands at the prompt to change the console username and password.
If you do not change the publicly known credentials, you will not be able to log in to the device again
after you log out.
Note
Router#configure terminal
Router(config)#username <your console username> privilege 15 secret 0 <your console password>
Router(config)#exit
Router#
Step 3
Log in to Cisco Business Edition 3000 Administrative Interface.
If this is your first login after running First Time Setup wizard, the Post Setup Tasks box appears. This dialog
box displays the commands you use to configure your gateway.
You can browse to Connections > Devices. Click the Generate CLI commands to configure the gateway
to issue the commands on the chosen gateway. The PSTN Gateway Configuration dialog box appears. This
dialog box displays the commands you use to configure your gateway.
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
134 OL-27022-01
Configuring the Gateway for the First Time

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
