Table 41: Settings on the Collect Logs tab
DescriptionSetting
To enable the system to collect debug level log data,
click Enable Logging. After you click this button, it
grays out and the Disable Logging button becomes
enabled. You can now attempt to reproduce your
system issue.
Turning on logging may impact system
performance, so enable logging only when
necessary. After you finish collecting log data,
remember to disable logging by clicking
Disable Logging.
Tip
Enable Logging
When you have reproduced the system issue, click
Disable Logging to stop the system from collecting
log data. After you click this button, it grays out and
the Enable Logging button becomes enabled.
Disable Logging
To prepare a log file, click Generate Log File.
You can generate a log file without
enabling/disabling the logging functionality
by clicking Generate Log File at any time and
downloading the current log collection file.
Tip
The system displays the progress of the log file
generation. When the log file is complete, a link
displays that you can click to download the file to
your PC. The link contains the time and date that the
log file was created.
Be sure to download the file to a location on
your PC that contains enough disk space to
accommodate the size of the log file.
Tip
Generate Log File
USB Flash Drive
Cisco USB flash drive allows you to perform the server diagnostics and collect the required log files when
the Cisco Business Edition 3000 Administrative Interface is not accessible. You can use the USB Flash Drive
tab to download the diagnostics file.
Ensure that the USB flash drive has a storage space of 4 GB. If there is not sufficient storage space, the
files smaller than 4 GB will be copied to the USB.
Note
To download the USB diagnostics file, click Download Diagnostics File. The USB diagnostics file allows
the Value Added Reseller (VAR) and Cisco Technical Assistance Center (TAC) to provide additional
troubleshooting assistance, especially when you cannot access the Cisco Business Edition 3000 Administrative
Interface.
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
218 OL-27022-01
USB Flash Drive

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
