CHAPTER 24
Diagnostics Settings
GUI: Cisco Business Edition 3000 Administrative Interface
The Diagnostics page allows you to run diagnostics for your system, gather diagnostic information for your
system, and download the diagnostic information. On the Diagnostics page, you can collect logs, enable or
disable loopback for T1/E1 interfaces, and download the USB diagnostics file.
For more information, see the How to Diagnose a Problem, on page 413.
The following topics contain information about the tabs and settings that are displayed on the Diagnostics
page (Monitoring > Diagnostics).
• Collect Logs, page 217
• USB Flash Drive, page 218
• Packet Capture, page 219
• Ping, page 220
• Gateway Loopback, page 220
• PCM Capture, page 221
Collect Logs
The following table describes the settings that you can use to enable or disable detailed logging, generate logs,
and download the log file under the Collect Logs tab.
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
OL-27022-01 217

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
