Example of Typical Deployment Model
The following illustration shows an example of a typical deployment model that includes the central site, two
remote sites, and the teleworker site. The central site includes the gateway, server, several routers, a Cisco
VG224 Analog Phone Gateway, and IP and analog phones. The remote sites include phones and routers. For
more information on the example, see the following sections.
Figure 4: Example of a typical deployment model
Table 5: Components of a typical deployment model
DescriptionNumber
Central Site1
Router2
Router with VPN3
Cisco Business Edition 3000 Server4
Cisco VG224 Analog Phone Gateway5
Cisco 2901 Integrated Services Router (ISR) (Gateway)6
Dual E1/TI connection7
Service Provider (Telecommunications Company)8
Internet9
Teleworkers Site10
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
OL-27022-01 53
Example of Typical Deployment Model

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
