DescriptionSettings
This field defines the desired impedance of the FXO Port. The
impedance values for various countries are:
• US—600
• EU (UK, Germany, Netherlands, Sweden, Norway, Italy, Spain,
Portugal, Poland, and Denmark)—270+750||150nF
• France—270+750||150nF
• Australia—220+820||120nF
• New Zealand—370+620||310nF
FXO Port Impedance
Outbound Call Routing Information
From the drop-down list, choose the discard digit instructions to use
for outbound call routing for the PSTN connection.
Choose one of the following from the drop-down list and click Save.
• Automatic—Select this option to use the digit discard
instructions based on the dial plan and retain the system-default
behavior.
• Set Manually—Select this option to customize the digit discard
instructions.
Click Edit to edit the digit discard instructions. The digit
discard instructions that appears depend on the numbering plan
that you choose from the Dial Plan drop-down list on the
System Settings > Dial Plan > General tab. For information
on configuring the digit discard instructions, see Digit Discard
Instructions Settings, on page 308.
Digit Discard Instruction
Inbound Call Routing Information
From the drop-down list, select the number of digits that will be
retained in the incoming called party number.
Remove all but the last
Enter the digits to prepend to the retained digits of the incoming
called party number. Valid entries include the digits 0 through 9, the
wildcard characters asterisk (*) and octothorpe (#), and the
international escape character +.
The final number (digits retained + prefix digits) must be
equal in length to the extension length in the system.
Note
Prepend the digits
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
OL-27022-01 297
Connection Settings
