DescriptionSettings
This field defines the amount of digital gain/attenuation, in decibels
(dB) applied to the signal sent from the PSTN to the SPA8800 device.
Increase this value if parties on the PSTN side are difficult to hear
by parties on your system or lower it if they are coming across too
loud. Range is -15 to 12 dB.
PSTN To SPA Gain
This field defines the smallest amount of time required by the
SPA8800 device to recognize a signal sent across the PSTN
connection as a ring signal. If a call from the PSTN is not signaling
a ring by a phone on your system, try increasing the validation time
until a phone on your system rings.
Ring Validation Time
Tip Ring Voltage Adjust
This field defines the amount of time to wait prior to the ring
indication occurring in a signal coming across the SPA8800 device.
Some amount of time, dependent on country, is required for caller
ID to be recognized for the call. Increase this time if a call that is
supposed to have caller ID is not showing anything on the display.
Decrease it if a ring appears to be occurring late or appears to be cut
off.
Ring Indication Delay
This field defines the minimum loop current that maintains the device
in an off-hook state. If the current is lower than this value, the device
will enter an on-hook state.
Operational Loop Current Min
This field defines the maximum time allowed for the ring to cross
between the higher and lower thresholds. It is expressed as the
maximum allowed 1/f in which f is the ring frequency.
Ring Timeout
This field defines the speed with which a call goes from off-hook to
on-hook when the phone is hung up.
On Hook Speed
This field defines the minimum voltage that can be detected as a
ring.
Ring Threshold
This field controls the current alarm threshold.Current Limiting Enable
This field sets the ringer impedance. Certain countries, like South
Africa, require a low ringer impedance.
Ringer Impedance
This field sets the voltage that must be maintained across a line to
designate that the line is in use. This parameter should match the
value used by the PSTN.
Line In Use Voltage
Click Finish to complete adding a PSTN connection to Cisco Business Edition 3000 server. You can add up
to 300 connections.
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
OL-27022-01 299
Connection Settings

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
