Control Techniques unidrive sp User Manual

Menu 10
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
170 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
SCL Drive RS485 serial comms loss to remote keypad
30
Refit the cable between the drive and keypad
Check cable for damage
Replace cable
Replace keypad
SLX.dF Solutions Module slot X trip: Solutions Module type fitted in slot X changed
204,209,214 Save parameters and reset
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
202,207,212
Feedback module category
Check value in Pr 15/16/17.50. The following table lists the possible error codes for the SM-Universal Encoder Plus, SM-Encoder
Plus and SM-Resolver.
Trip Diagnosis
Error
code
Trip Description Diagnostic
0 No trip No fault detected
1
Encoder trip: Encoder power
supply overload
Check encoder power supply wiring and encoder current requirement
Maximum current = 200mA @ 15V, or 300mA @ 8V and 5V
2 Encoder trip: Wire break
Check cable continuity
Check wiring of feedback signals is correct
Check supply voltage level
Replace feedback device
3
Encoder trip: UVW phase offset
incorrect whilst running
Check the encoder signal for noise
Check encoder shielding
Check the integrity of the encoder mechanical mounting
Repeat the offset measurement test
4
Encoder trip: Feedback device
communications failure
Ensure encoder power supply is correct
Ensure baud rate is correct
Check encoder wiring
Replace feedback device
5
Encoder trip: Checksum or CRC
error
Check the encoder signal for noise
Check the encoder cable shielding
6
Encoder trip: Encoder has
indicated an error
Replace encoder
7 Encoder trip: Initialisation failed
Check the correct encoder type is entered into Pr 15/16/17.15
Check encoder wiring
Check supply voltage level
Replace feedback device
8
Encoder trip: Auto configuration
on power up has been
requested and failed
Change the setting of Pr 15/16/17.18 and manually enter the number of turns (Pr 15/
16/17.09) and the equivalent number of lines per revolution (Pr 15/16/17.10)
9 All Thermistor trip
10 All Thermistor short circuit
11
Resolver: Poles not compatible
with motor
Check that the correct number of resolver poles has been set in Pr 15/16/17.15.
74 All The Solutions Module has over-heated
