This position is taken from the position feedback device and is not affected by the marker or the freeze inputs.
Each time the marker becomes active the non-marker position values (Pr x.29 and Pr x.30) are sampled and stored in Pr x.32 and Pr x.33.
x.29 Non-marker reset revolution counter
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 65,535 revolutions
Update rate Combined update time. This module adds 4ms to the combined update time.
x.30 Non-marker reset position
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 65,535 (1/2
16
ths of a revolution)
Update rate Combined update time. This module adds 4ms to the combined update time.
x.32 Marker revolution counter
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 65,535 revolutions
Update rate Combined update time. This module adds 4ms to the combined update time.
x.33 Marker position
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 65,535 (1/2
16
ths of a revolution)
Update rate Combined update time. This module adds 4ms to the combined update time.
x.35 Freeze revolution counter
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 65,535 revolutions
Update rate Combined update time. This module adds 4ms to the combined update time.
x.36 Freeze position
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 65,535 (1/2
16
ths of a revolution)
Update rate Combined update time. This module adds 4ms to the combined update time.
