DVP-15MC Series Motion Controller Operation Manual
8-156
_8
 The rule for the conversion from Boolean to Bit-String is shown in the following table. (The
format of the bit-string value and the hexadecimal expression are to be confirmed.)
Boolean
Bit String
BYTE
WORD
DWORD
LWORD
FALSE
16#00
16#0000
16#0000_0000
16#0000_0000_0000_0000
TRUE
16#01
16#0001
16#0000_0001
16#0000_0000_0000_0001
 BOOL to Integer
 Relevant instructions:
 The rule that Boolean data are converted into Integer data is as the following table shows.
Boolean
Integer
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
FALSE
0
0
0
0
0
0
0
0
TRUE
1
1
1
1
1
1
1
1
 BOOL to Real number
 Relevant instructions:
 The rule that Boolean data are converted into Real-number data is as the following table
shows.
Boolean
Real
REAL
LREAL
FALSE
0
0
TRUE
1
1
BOOL_TO_USINT
EN
ENO
Out
In
BOOL_TO_SINT
EN
ENO
Out
In
BOOL_TO_UINT
EN
ENO
Out
In
BOOL_TO_INT
EN
ENO
Out
In
BOOL_TO_UDINT
EN
ENO
Out
In
BOOL_TO_DINT
EN
ENO
Out
In
BOOL_TO_ULINT
EN
ENO
Out
In
BOOL_TO_LINT
EN
ENO
Out
In
BOOL_TO_REAL
EN
ENO
Out
In
BOOL_TO_LREAL
EN
ENO
Out
In
