Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-339
8_
FB/FC
Explanation
Applicable model
FC
GetBitOffsetValue is used to read the value of the specific bit of the
specified address and display it in the output parameter.
DVP15MC11T
DVP15MC11T-06
GetBitOffsetValue
StartRegister GetBitOffsetValue
Offset
EN ENO
 Parameters
Parameter name Meaning Input/ Output Description Valid range
StartRegister Starting address Input
Specify the starting
address
Offset
How many bits
are offset
Input
Specify the offset value by
regarding the bit0 of the
variable that StartRegister
points to as the reference
0~1023
GetBitOffsetValue
The read bit
value
Output The read bit value TRUE / FALSE
Boolean
Bit string Integer
Real
number
Time, date
Pointer
BOOL BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT INT DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
Pointer To XX
StartR
egister
●
Offset
● ●
GetBit
Offset
Value
●
Note:
1. The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the
data type.
2. xx of the ‘Pointer To xx’ data type includes Bit string and Integer data types.
 Function Explanation
The GetBitOffsetValue instruction is used to read the value of the specified bit and the output
GetBitOffsetValue shows the read state value. The StartRegister parameter is a Pointer-type variable. The
Offset parameter specifies the offset value which regards the bit0 of the variable the StartRegister parameter
points to as the reference. The GetBitOffsetValue parameter shows the state value of the specified bit, which
is TRUE or FALSE.
If the specified offset value exceeds the range of the starting address of StartRegister, the operation will be
performed according to the corresponding offset address which regards the StartRegister as the starting
address.
See more in the following example.
