DVP-15MC Series Motion Controller Operation Manual
8-210
8.14.2.7 ETH_Socket_Manage
FB
ETH_Socket_Manage is used for managing Socket TCP/UDP.
ETH_Socket_Manage
Enable Valid
ETH_Socket_Manage_instance
EnableSocket SocketReady
PhysicalLinkError
Input Parameters
Parameter name Function Data type
Validation timing
Enable
The instruction is executed
when Enable changes from
BOOL
TRUE or FALSE
(FALSE)
EnableSocket Enable the Socket. BOOL
TRUE or FALSE
(FALSE)
changes from
Note:
ETH_Socket_Manage is to enable the Socket function. Other Socket–related instructions can not be used until
the instruction is executed.
Output Parameters
TRUE when the instruction output is valid.
TRUE when enabling the Socket is successful.
PhysicalLinkError
TRUE when the physical connection to Ethernet
port of the controller is disconnected.
BOOL TRUE/FALSE
Output Update Timing
Timing for changing to TRUE
Timing for changing to FALSE
Valid
When Enable changes to TRUE.
When Enable changes from TRUE to
SocketReady
When enabling the Socket is
successful.
When Enable changes from TRUE to
FALSE.
When EnableSocket changes from
PhysicalLinkError
When Enable changes to TRUE
and the physical connection to
Ethernet port LAN2 of the
controller is disconnected.
When Enable changes from TRUE to
FALSE.
When the physical connection to
Ethernet port LAN2 of the controller
To Next Page
