Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-145
8_
FB/FC
Explanation
Applicable model
FC
MUX is used for selecting one of two or more variables or constants and the
result is output to Out.
DVP15MC11T
DVP15MC11T-06
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
K Gate Input Gate
Depends on the data type of the
variable that the input parameter is
connected to.
In0, In1 to
InN
Selections Input
The selections can be
added or removed while
the program is being
written. The maximum
number of selections is 8.
N=2~8.
Depends on the data type of the
variable that the input parameter is
connected to.
Out
Selection
result
Output Selection result
Depends on the data type of the
variable that the output parameter is
connected to.
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD
DWORD
LWORD
USINT
UINT UDINT ULINT SINT INT DINT LINT REAL
LREAL
TIME
DATE
TOD
DT
STRING
K
●
In0,
In1
to
InN
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Out
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data
type.
 Function Explanation
 Based on the selection condition K, the MUX instruction selects one of In0~InN and the selection
result is output to Out. The value of Out corresponds to the value of K as shown in the following table.
MUX
EN ENO
K Out
In1
In0
InN
.
.
.
