Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-217
8_
8.14.2.10 ETH_Socket_Send
FB/FC
Explanation
Applicable model
FB
ETH_Socket_Send is used for sending Socket data.
DVP15MC11T
DVP15MC11T-06
ETH_Socket_Send
Execute
ETH_Socket_Send_instance
Abort
Done
Sent
Sending
SocketNum
CyclicRun
CycleTime
Send_Buffer_Address
Send_Length
Busy
Active
Aborted
Error
ErrorID
 Input Parameters
Parameter name Function Data type
Valid range
(Default)
Validation timing
Execute
The instruction is
executed when Execute
changes from FALSE to
TRUE.
BOOL
TRUE or FALSE
(FALSE)
Abort
Abort the instruction
execution.
BOOL
TRUE or FALSE
（FALSE）
SocketNum
Specify the number of the
Socket.
USINT
1~8
（0）
When Execute
changes from
FALSE to TRUE
CyclicRun
Set whether to cyclically
send data or not.
TRUE: Cyclic sending,
FALSE: Only one-time
data sending
BOOL
TRUE or FALSE
（FALSE）
When Execute
changes from
FALSE to TRUE
CycleTime
Set the time of a cycle.
Unit: ms
UINT
0~65535
（0）
When Execute
changes from
FALSE to TRUE
Send_Buffer_Addre
ss
Specify the start register
for storing the sent data.
USINT
%MB0~%MB65
535
When Execute
changes from
FALSE to TRUE
Send_Length
Set how many Bytes of
data to be sent.
UINT
0~200
（0）
When Execute
changes from
FALSE to TRUE
Note:
The input parameter Send_Buffer_Address represents the first register address where the data the controller
sends are stored, and the parameter Send_Length is the length of the data sent by the controller. The two
input values must be set.
