Delta DVP-15MC Series - Bool_To_; Data Type Conversion Instructions

Chapter 8 Logic Instructions
8-155
8_
Data Type Conversion Instructions
FB/FC
Explanation
Applicable model
FC
BOOL_TO_*** instructions convert boolean data into the data of basic data
types. “***” can be any basic data type.
DVP15MC11T
DVP15MC11T-06
 Parameters
Parameter
name
Meaning Input/ Output Description Valid range
In Data to convert Input Data to convert
Depends on the data type of the
variable that the input parameter is
connected to.
Out Conversion result Output Conversion result
Depends on the data type of the
variable that the output parameter is
connected to.
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL
BYTE WORD DWORD LWORD
USINT
UINT
UDINT
ULINT SINT INT DINT LINT REAL
LREAL
TIME
DATE
TOD
DT
STRING
In
●
Out
The data type of
Out
must be the same as “***” of the instruction name.
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data
type.
 Function Explanation
 BOOL to Bit String
 Relevant instructions:
BOOL_TO_***
EN
ENO
OutIn
BOOL_TO_BYTE
EN
ENO
Out
In
BOOL_TO_WORD
EN
ENO
Out
In
BOOL_TO_DWORD
EN
ENO
Out
In
BOOL_TO_LWORD
EN
ENO
Out
In
